2/3POS High Voltage plastic connector with shield(RED)


Main applying to battery heating positive temperature coefficient(PTC), OBC, PDU, Compressor.

Code HV_CONNECTOR_RED





2_3 POS High Voltage Plastic Connectors with shield(RED)

Product Description :
■     2/3 POS
■     Plastic shell
■     Locking handle and
■     Secondary locking structure
■     High protection degree
■     IP6K9K、IP68
■     6 anti-misplug key position
■     Cable section: 2.5mm
²--4mm²

Product Application :
■     Current Rating: 22A=2.5mm, 25A=3mm, 30A=4mm
■     Voltage Rating: 1000V DC
■     Shielding: Option
■     HVIL: Option
■     Working Temperature: -40°C­ - +140°C
