Features
1. Output Power: 150KW
2. Input Voltage: 90~500VDC
3. Output Voltage: 400-750VDC、400-900VDC
4. Rated Output Current：300A
5. Dimensions: 605x545x105mm
6. Weight: ≤33KG
7. Cooling System: Liquid, flow rate ≥20L/min
8. Protection Level: IP67
9. Communication Method: CANBUS
10. Enclosure: Aluminum alloy
11. Software: Digital software design
