OBC_20KW_85~265VAC_450~750VDC_Liquid_Model No.:ATC20K-220S640-W
Model No.:ATC20K-220S640-W
Output Power：20KW
Input Voltage：85~265VAC
Output Voltage：450~750VDC
Cooling System：Liquid
IP Rating：IP67
Communication：CAN-BUS
Code ATC20K-220S640-W
Download: 20KW ON BOARD CHARGER LIGUID
Features
● Output Power：20KW
● Input Voltage：85~265VAC
● Output Voltage：450~750VDC
● Dimensions：588x346x103mm
● Cooling System：Liquid
● IP Rating：IP67
● Communication：CAN-BUS
● Enclosure: Aluminum alloy made
● Software: Digital software design
Specification
| Description | Parameters | Remark | |
| Output Power | 20KW | ||
| Input voltage range | 85~265VAC | ||
| Output voltage range | 450~750VDC | ||
| Low voltage wake-up | 12/24Vdc&200mAmax (WAKE_UP signal) | Wake up BMS/VCU | |
| Current accuracy | ±3% | ||
| Voltage accuracy | ±1% | ||
| Output maximum current | 33A | ||
| Efficiency | ≧ 94% | @nominal voltage | |
| Static Current | ≦4mA | Sleep mode/ consume batter current at stop status | |
| Cooling System | Liquid | ||
| IP Rating | IP67 | ||
| EMC characteristics | GB/T 18387-2008, EN 55022 | ||
| Protection | Input OVP/UVP, output OVP/UVP,OTP, OCP, output short circuit protection, CAN communication breakdown protection | ||
| Weight | ≦25KG | ||
