Model No.: AT-TZ160X13H-96LT
Batter voltage:96VDC
Rated power:13KW
Peak power:25KW
Rated speed:4775rpm
Peak speed:8200rpm
Rated torque:26N,m
Peak torque:85N.m
代碼: AT-TZ160X13H-96LT
Model No.: ATM110K540-V6H4D110
DC supply voltage range: DC 350V—750V
Protection level of control box:IP67
Rated Power(kW):110KW
Peak Power(kW):180KW
Efficiency:≥98%
代碼: ATM110K540-V6H4D110
Model No.:ATM7K5-540S24M-V6H4D7.5G
DC supply voltage range: DC 350V—750V
Controller communication mode:CAN 2.0
Low voltage power consumption:≤12W
Heat dissipation:0.2KW
Efficiency:≥93%
代碼: ATM7K5-540S24M
Model No.: iPDU 12
Voltage: 1500VDC
Current: 300A
Dimension: 255*130*140 mm
ISO9001 IATF/TS16949 ISO14001 certified company
plastic housing 、epoxy and circuit board assembly meets 94-V0
代碼: IPDU12
･ Security System
･ Current Control System
･ Power Protection System
･ Power integration & Distribution System
･ Communication and CAN Acquisition System
代碼: MULTI_INTEGRATED_PDU
･ Security System
･ Current Control System
･ Power Protection System
･ Power integration & Distribution System
･ Communication and CAN Acquisition System
代碼: PDU
Main applying to battery heating positive temperature coefficient(PTC), OBC, PDU, Compressor.
代碼: HV_CONNECTOR_RED
Current rating:16A(For2.5mm2cable);
25A(For4mm2cable);
40A(For6mm2cable);
Voltage rating:700V DC
Withstand voltage:3000V AC 1 min
Insulation resistance:3000MΩ
Shielding:optional
HVIL: optional
代碼: REM_II
■ Fuse current: Voltage 750V.DC 200A - 400A ; Voltage 500V.DC 500A ■ Current Rating : 250A
代碼: HV_CONNECTOR_MSD7
