10MW/20.64MWh Energy Storage System  |Products|Energy Storage System(ESS)

10MW/20.64MWh Energy Storage System


Model No.: AT10MW20.64MWH ESS

Battery Modules

Code ESS_01





Download:  AT10MW20.64MWHESS_Specification.pdf


Battery Modules Specification :


No.

Specification

Parameter

1

Battery

3.2V 280Ah LFP Cell

2

Series and Parallel Circuits

2P12S

3

Rated Capacity

560Ah

4

Rated Voltage

38.4V

5

Rated Energy

21.504kWh

6

Standard charging conditions

Constant Power (CP), Constant Current (CC), Constant Voltage (CV)

Power: 10.752kW (0.5CP)

Termination voltage: 32.4V

7

Standard discharge conditions

Constant Power (CP), Constant Current (CC)

Power: 10.752kW (0.5CP)

Termination voltage: 32.4V

8

Max. discharge power

21.504kW1CP

9

Cycle Life

≥6000 times @25℃, 0.5C charge and discharge,

Cell decays to 80% of the initial capacity under 90% DOD operation

10

System Voltage

≤1500V

11

Operating Temperature Range

-15 ~ 40 ℃

12

Storage Temperature

-15 ~ 40 ℃, the SOC should be kept at 30%50%, and not exceed 6 months.

13

Humidity

≤85% RH (non-condensing)

14

Weight

150kg

15

Dimension

982*450*238mmD*W*H
