DC/DC_240W_36~84VDC_12V_Heat sink


Output Power:240W

Input Voltage:36~84Vdc

Output Voltage:12±5%VDC

Cooling System:Heat sink

Code 240KW_DCDC





Download:DC-DC Converter 240W


Specifications


Specifications

Value

Range

Unit

Remark









Electricl



Input

Rated Input Voltage



36~84

VDC



Rated Input Current

36V/7.4A; 84V/3.2A



A

Estimated value ,will

be fixed before MP







Output

Rated Output Voltage

12

±5%

VDC



Rated Output Current

20

±2%

A

35A(PEAK)

Rated Output DC Power

240



W



Efficiency

>90



%



Ripple & Noise

120



mVp-p













Protection





Input

Input Over-voltage

Protection(OVP)

100

±5%

VDC



Input Under-voltage

Protection(UVP

32

±5%

VDC



Output Over Current Protection(OCP)

9.4

±2%

A





Output

Output Over Current Protection(OCP)

21

±2%

A



Short circuit protection

25



A



Other

Over temperature

protection(OTP)

90



°C







Feature





System indicator

N/A





(Standby)



N/A





(Error)



Input reverse protection

Y









Isolated/Non-isolated

Isolated











Safety and EMC





Isolation voltage

I/P-O/P:1.5kVac I/P-FG :2kVac

O/P-FG:0.5kVac











Insulation resistance

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC

at 25°C/70% RH









EMI/EMC

CE









Environmental



Operating temperature

-20°C~85°C









Working humidity

5% to 95% RH









Mechanical



IP rating

IP67









Cooling method

Heat sink









Dimension(L*W*H)

210*100*50



mm

(Estimated)
