300W DC/DC converter


Model No.:AR300W-2713V

Power:300W

Input Voltage:18~36 VDC

Output Voltage:13±0.5V

Output Current:10A

代碼 AR300W-2713V




Download: 300W DC/DC converter Specificaiton

Feature

● NOMINAL INPUT VOLTAGE :27V.
● INPUT VOLTAGE RANGE AT RATED LOAD :18~36 VDC
● OUTPUT VOLTAGE RANGE: 13±0.5V
● RIPPLE VOLTAGE AT NOMINAL CONDITION:<250mVPPp AT 25˚C
● NOMINAL OUTPUT CURRENT : 10A.
● INSULATION RESISTANCE > 1 MEGA OHM.
● TESTING TO BE DONE AS PER SIGNED OFF CTR
● COMPONENT SHOULD MEET THE ELV/RoHS REQUIREMENT
● INGRESS PROTECTION: IP65.
● COMPONENT MEETS Pulse 5b TEST FOR 24V SYSTEM AT Us*= 65V , Ri= 1Ohm.
● COMPONENT MEETS RADIATED EMISSION =Class 3
● COMPONENT MEETS CONDUCTED EMISSION=Class3.
● Box size (id)- 450x380x190
● Qty- 18 nos.
● Weight- 8.5 kg3
